(Christmas Sale 2025) 12″ Sound System Set SONORE ACTIVE PR12P Speaker + SINOMIX 8 Channel Mixer + DYNAMAX Wireless Mic

Package Include

SONORE PR-12P 12″ ACTIVE SPEAKER WITH MCMC
SONORE 8 CHANNEL STEREO MIXER WITH DIGITAL FX & 24 BIT/96K USB INTERFACE
DYNAMAX U8092 DUAL UHF HANDHELD WIRELESS MICROPHONE SYSTEM (WITH MCMC)
MicronSonic T-609B BLUETOOTH AUDIO RECEIVER (WITH MCMC)
FOC SONORE BRAND 12″ SPEAKER STAND SP-19B
FOC ERC-101J 3 PIN XLR SOCKET (BLUE)
FOC ERC-102P 3 PIN XLR PLUG (RED)
FOC MARUNI CABLE
FOC MC-3376C 3.5MM STEREO PLUG TO 2RCA W/3M CABLE
FOC SPONGE MIC COVER (YELLOW,RED / BLACK,BLACK ) (2PCS/PACK)

SPECIFICATIONS — SONORE PR-12P (12” Active Speaker)
Speaker Type: 12” 3-way full-range active speaker
LF Driver: 12″ woofer (2″ voice coil)
MF Driver: 3 × 3″ woofers
HF Driver: 1.34″ Ti tweeter
Frequency Response (–6 dB): 40 Hz – 20 kHz
Max SPL (1m): 123 dB
Impedance: 4Ω
Amplifier: Class-D 3-way amplifier
Power Output (RMS): 350W (LF) + 100W (MF) + 50W (HF)
DSP Module: Music, Live, Speech, Flat
DSP: DSP-100, 96 kHz, 24-bit DSP processor with presets
Protection: Short circuit, overheating, over-current
Inputs: 2 × XLR / 6.3mm combo, 1 × RCA line in
Output: 1 × XLR line out
Bluetooth: Yes, supports TWS function
Indicators: Power, signal, limit, DSP mode
Enclosure: H-PP with painting, side handle, 35mm pole mount
Grille: Metal grille with acoustic fabric
Power Supply: 100–240V, 50/60Hz
Dimensions: 61 cm × 35 cm × 35 cm
Weight: 17 kg

SPECIFICATIONS — SONORE MIX8UFX (8-Channel Stereo Mixer)
Max Input Level:
MIC: +24 dBu
Line: +24 dBu
Other Line: +20 dBu
Max Output Level:
XLR: +26 dBu
TRS: +20 dBu
Frequency Response: 20 Hz – 30 kHz (±0.5 dB)
CMRR @ 1 kHz: 75 dB
THD+N: <0.01% (Channel to Mix Out)
Crosstalk @ 1 kHz:
Fader Shut: 85 dB
Inter Channel: 82 dB
L/R Out: –82 dBu
AUX Mix Noise: –82 dBu
Noise (22 Hz – 22 kHz):
Residual Output: –90 dBu
L/R Main Mix: –82 dBu

📌 EQ SECTION
Mono EQ:
LF: ±15 dB @ 12 kHz
HM Peak/Dip: ±15 dB @ 2.5 kHz
Stereo EQ:
LF: ±15 dB @ 8 Hz
LF Shelving: ±15 dB @ 12 kHz
HM Peak/Dip: ±15 dB @ 2.5 kHz
LF Shelving: ±15 dB @ 8 Hz
📌 INPUTS / OUTPUTS
Mono Channel:
XLR Balanced (2 hot, 20 ohm) Sensitivity –60 to +14 dBu
TRS Balanced (10k ohm), Sensitivity –40 to +14 dBu
Phantom Power: +48V
Stereo Channel:
TRS Unbalanced (10k ohm), Sensitivity –40 to +14 dBu
2-Track Input:
RCA Unbalanced, 4k ohm, –2 dBu
2-Track Output:
RCA Unbalanced, 75 ohm, –2 dBu
DSP Processor: 24-bit Sigma-Delta, 64/128-oversampling, 40 kHz rate
L/R Output:
XLR Balanced, pin 2 hot, 75 ohm, +4 dBu Max +22 dBu
SUB 1 / SUB 2:
XLR Balanced, +4 dBu Max +22 dBu
FX/AUX Output: TRS Balanced, 75 ohm, –2 dBu Max +18 dBu

Headphones:TRS Jack, 30–600 ohm recommended

📌 PHYSICAL

Dimensions: 36 cm × 32.2 cm × 7.8 cm

SPECIFICATIONS — DYNAMAX PHWLDX-U8092 (Dual UHF Wireless Mic)

Frequency Range: 670 – 690 MHz
Frequency Response: 50 Hz – 15 kHz
Selectable Channels: 30 CH × 2
Modulation Mode: FM
Max Offset Frequency: ±30 kHz
S/N Ratio: >105 dB (A-weighted)
Distortion (1 kHz): <0.3%
Working Distance: Up to 100 ft (open area)
Battery Life: Up to 7–8 hours
Charging Time: 3–4 hours
